| Fiber alignment |
Core cladding |
| Motor number |
6 motors |
| Splicing time |
8s |
| Heating mode |
18s can be customized according to the external environment |
| Fiber type |
Single-mode fiber (SM/F/0.65Z), BIF/C 8577; Suitable for single mode, multi-mode, bare fiber, tail fiber, drop cable, lumber, invisible fiber fusion |
| Cladding diameter |
80-150 μm |
| Splicing loss |
0.02dB (SIM), 0.01dB (MM), 0.04dB (OS/N2DS) |
| Splicing mode |
Automatic focusing core alignment, conventional/high precision welding |
| Splicing way |
Automatic, semi-automatic |
| Fiber holder |
These in one fixture, no need to change, suitable for single/multi-mode, multi-core cable/bare fiber, tail fiber, jumper fiber/drop cable |
| Battery capacity |
5200mAh large capacity lithium battery; charging time ≤3.5h; can continuously weld and heat about 160 cores |
| Magnification |
320x (X or Y axis single display), 200x (X and Y axis dual display) |
| Fiber diameter |
Coating diameter: 80-150μm / Coating diameter: 100-1000μm |
| Cutting length |
Coating layer 250μm below: 8-16 mm/coating layer 250-1000μm: 16mm |
| Heat shrink tube |
60mm, 50mm, 40mm, 25mm |
| Tensile testing |
Standard 2N |
| Display |
5-inch TFT color display screen |
| External lighting |
USB port can be connected with an EXTERNAL LED light, convenient for night construction |
| Charge the mobile device |
The USB port can charge mobile devices such as mobile phones |
| Boot time |
1st, boot into working mode |
| Data storage |
Unlimited; machine storage 1000 groups, excess can be stored inthe server; data can be exported |
| Wireless communication |
Based on Bluetooth 4.2 protocol standard; working band 2.4GHz; maximum transmission range 60m |
| Software upgrade |
Mobile phone APP Internet update, enable Bluetooth synchronization, upgrade machine software |
| Management function |
The equipment owner can be bound as the highest authority; remotely view welding records, time, and loss via a mobile APP; set welding times or working times; manage single or multiple equipment |
| Interface |
USB 2.0 (Type A) for connecting external LED lights and charging mobile devices |
| Return loss |
Better than 60 dB |
| Product protection |
Waterproof, dustproof, and fall-proof |
| Power supply |
Input AC100-240V 50/60Hz; output DC13.5V 8A; current power mode can be identified; real-time monitoring of battery level |
| Work environment |
Temperature: -15 ~ +50°C; humidity: < 95%RH (no condensation); altitude: 0 ~ 5000m; maximum wind speed: ≤15m/s |
