GSG-05-50mm-UPC Vertical Fiber Optic Fast connector

GSG-05-50 mm-UPC Vertical Fiber Optic Fast connector utilizes pre-polishing technology, enabling quick and tool-free fiber optic termination on-site. This connector can be effortlessly installed without the need for tools, simplifying the process, saving time, and reducing labor costs. It eliminates the need for traditional welding or adhesive steps, significantly cutting down on installation time and expenses while boosting work efficiency.
GSG-05-50 mm-UPC Vertical Fiber Optic Fast connector's low insertion loss and high return loss characteristics guarantee superior signal transmission quality, making it ideal for applications requiring high data integrity and minimal signal degradation.
 As an ideal solution for fiber optic network installations, it is well-suited for diverse fiber optic communication systems, including data centers, local area networks, and wide area networks, enhancing the efficiency and reliability of fiber optic connections.

  • Item LX-R05(50mm)-UPC
    Length 50mm
    Ferrules SM/UPC / SM/APC
    Inner Diameter of Ferrules 125um
    Insertion Loss AVG≤0.3dB MAX≤0.5dB
    Return Loss UPC≥50dB / APC≥55dB
    Working Temperature -20~ +75 °C
    Storage Temperature -40~+85°C
    Mating Times 500Times
    Cable Diameter Drop cable: 2.0*3.0 mm/2.0*5.0 mmRound cable: 5.0 mm/3.0mm/2.0mm/0.9mm
