GSG-12B-52mm-APC Fiber Optic Fast connector

GSG-12B-52 mm-APC Fiber Optic Fast connector uses mechanical termination technology, eliminating traditional welding or bonding steps, greatly shortening installation time. No special tools are required, and one person can complete on-site termination, which is suitable for small spaces or emergency repair scenarios.
GSG-12B-52 mm-APC Fiber Optic Fast connector can optimize optical path design, reduce signal attenuation, and is suitable for high-speed data communications.
GSG-12B-52 mm-APC Fiber Optic Fast connector, weather-resistant materials ensure stable performance in severe cold, high temperature, or high humidity environments.

PREV：GSG-12A-52mm-UPC Fiber Optic Fast connectorNEXT：GSG-12B-52mm-UPC Fiber Optic Fast connector
  • Details
  • contact us
  • Item LX-DR12-B(52mm)-APC
    Length 52mm
    Ferrules SM/UPC / SM/APC
    Inner Diameter of Ferrules 125um
    Insertion Loss AVG≤0.3dB MAX≤0.5dB
    Return Loss UPC≥50dB / APC≥55dB
    Working Temperature -20~+759C
    Storage Temperature -40~ +85°C
    Mating Times 500Times
    Cable Diameter Drop cable:2.0*3.0mm/2.0*5.0mm/2.0*1.6mm
